Qingdao Hanlinrui Machinery Co., Ltd focuses on customizing high-quality CNC machining products to meet the unique needs of customers, for example, Shaft Piston. We have state-of-the-art machinery and a team of highly skilled engineers to provide customized solutions to various industries including aerospace, automotive and medical. Qingdao Hanlinrui Machinery Co., Ltd’s dedication to quality and customer satisfaction makes them a trusted partner in the CNC machining sector.
Qingdao Hanlinrui Machinery Co., Ltd focuses on customizing high-quality CNC machining products to meet the unique needs of customers. We have state-of-the-art machinery and a team of highly skilled engineers to provide customized solutions to various industries including aerospace, automotive and medical. Qingdao Hanlinrui Machinery Co., Ltd’s dedication to quality and customer satisfaction makes them a trusted partner in the CNC machining sector.
In a shaft-piston drive system, the reciprocating motion of the piston and the rotational motion of the shaft are interrelated. Parameters such as the stroke length and speed of the piston as well as the rotation angle and speed of the shaft can be adjusted and optimized according to specific needs. This driving method has the advantages of simple structure, compactness, and easy maintenance, and can make full use of the power generated by each piston stroke to improve energy conversion efficiency.
|
Diameter (mm) |
10 - 100 |
|
Stroke Length (mm) |
50 - 300 |
|
Material |
Aluminum, Steel, Plastic |
|
Pressure Rating (bar) |
10 - 350 |
|
Temperature Range (°C) |
-20 to 150 |
|
Seal Type |
O-ring, Lip seal |
|
Weight (kg) |
0.5 - 5.0 |
|
Operating Medium |
Air, Oil, Water |
|
Mounting Type |
Flanged, Threaded |
■ Piston Design: Shaft pistons are usually cylindrical or similar in shape and they move in a straight line along the main axis of the engine.
■ Cylinder Layout: The cylinders of a shaft piston engine are usually arranged linearly, unlike the radial arrangement of traditional reciprocating engines.
■ Connecting Rod Mechanism: The shaft piston is connected to the crankshaft through a special connecting rod mechanism, which converts the linear motion of the piston into the rotational motion of the crankshaft.
■ Compact Structure: Shaft piston designs are generally compact, making efficient use of space and suitable for a variety of mechanical equipment.
■ Strong Adaptability: The shaft piston drive system can be adjusted and optimized according to specific needs, such as piston stroke, speed, and shaft rotation angle, to adapt to different working conditions and application scenarios.
Shaft pistons are widely used in various applications across different industries.
■ Compact Structure: Since the piston moves along the axis, it can be designed to be more compact, suitable for occasions with limited space.
■ High Power Transmission Efficiency: The linear-moving piston can convert combustion power into rotational power more directly.
■ Simple Maintenance: Linear arrangement of cylinders and pistons may simplify the design of lubrication and cooling systems.
■ High Energy Conversion Rate: The shaft piston design can make full use of the power generated by each piston stroke, reduce energy loss, and improve energy conversion efficiency.
■ Stable And Reliable Operation: The shaft piston drive system has a simple structure, close cooperation between components, stable and reliable operation, and relatively low maintenance costs.
■ What materials are used for shaft pistons?
Shaft pistons are typically made from aluminum, steel, or plastic, depending on the application.
■ What industries use shaft pistons?
They are used in automotive, aerospace, construction, and manufacturing, among others.
■ How do I choose the right size for a shaft piston?
The size depends on the application requirements, including the stroke length and pressure ratings needed.
■ Can I customize the products?
Yes. We can provide the design of the product model according to your requirements.please contact us for your customized design need.
■ How can I get quotation?
Send us your requirements and leave your email, we will send you quotation within 24 hours.
